S.No

Parameter

Specifications

1

General features :

1.1 Core: ARM® Cortex®-M4 32-bit CPU with FPU(72 MHz).

1.2 GPS + IRNSS(Location, speed, heading, timestamp) data pulling and
sending frequency capability of less than or equal to 2 sec.

1.3 Location on demand on GPRS/SMS.

1.4 Memory to store min 50000 positional log.

1.5 Configurable fallback option in case of GPRS failure via SMS

1.6 Capability to send Serving and Adjacent four Cell ID with NMR(Network Measurment Report).

2

GPS
IRNSS
Specs

2.1 GPS L1 Band Receiver (1575.42MHz) Ultra high navigation sensitivity with Multi navigation constellation: GPS/ GLONASS/NAVIC/IRNSS(optional)GNSS Receiver channels: 99 acquisition/ 33 tracking channels,PowerfulAGPSfunctions:Autonomous AGPS EASY.

2.2 Acquisition sensitivity : better than -149 dBm.

2.3 Tracking Sensitivity :- better than -167 dBm.

2.4 Horizontal position Acuuracy:-Autonomous: <2.5m CEP 5meter.

3

GPRS Communication

3.1 GSM Quad-band:850/ 900/ 1800/ 1900MHz.GPRS Class 12,Coding Schemes:CS1, to CS4 USSD.

3.4 Support – SMS, Voice, Data, GPRS, TCP/IP.

4

Power

4.1 Input voltage range 6-76 Volts.

4.2 Active mode Avg150mA during transmission, 50mA during tracking and <20mA during Sleep Mode.

5

SIM Interface

5.1 Supports both two Embedded and normal (Micro SIM).

6

Ports

6.1 Serial port RS232 , 2 Analog Input( For analog inputs like Fuel, temperature) , 4 Digital input, 2 Digital output. Ignition Sensing.

7

Battery backup

7.1 External vehicle battery and Internal Battery for 8 hrs.

8

Operational Environment
Variables

8.1 Temperature range ; -30° C to 805°C.

8.2 Humidity Level: 5% to 95% non-condensing at +40°C

8.3 Dust, temperature, vibration and Water Splash resistant

8.4 IP 65 rated or equivalent. With heat resistant, Vibration proof,
tamper proof.

8.5 UL Fire retardant enclosure.

8.6 Vibration and Shock : to meet SAE standards.

9

Antenna

7.1Internal GPRS antenna. Internal GPS Patch Antena and supports External Antena.

10

CAN BUS

9.1 Supports CAN/OBD port for integration with Bus CAN port.(optional)

11

FOTA

10.1 Supoorts Firmware over the Air

12

Motion Sensor

11.1 3 Axis Accelerometer and 3 Axis Gyrometer.

13

Additional Feature

11.1 Status LED‘s to indicate Power, GPS and GPRS status.

11.2 Over the air configuration of parameters

11.3 Remote administration & firmware update over the air

11.4 Reset: Power on reset and Hard reset switch

11.5 Store and forward feature for network dark zone.
